Battery Felicity Solar 23.5 kWh LiFePo4 FLA48460-EU, Low Voltage
3 photosListed capacity23.5 kWh
ManufacturerFelicity Solar
CategoryBattery
Description
Battery Felicity Solar, reference FLA48460-EU. Capacity of the configuration listed: 23.5 kWh.
Rated voltage: 51.2 V. Technology: LiFePO4, Lithium Iron Phosphate. Protection: IP21. Dimensions: 718 × 380 × 990 mm. Weight:
The nominal capacity of 23.5 kWh shall be checked on the manufacturer's fiche. The certificate available in the source mentions the family FLA48460TG2-EU; the applicability to the delivered variant is confirmed.
The specifications below shall keep the operating conditions and configurations declared in the documentation. Those technical guarantees are those from the source; commercial conditions NORDLINE are confirmed in the quotation.
Technical specifications
Identification
- Manufacturer
- Felicity Solar
- Model / reference
- FLA48460-EU
Product configuration
- Configuration capacity listed
- 23.5 kWh For the product or package listed; the expansion values are presented separately.
Technical specifications
- Model
- FLA48460-EU
- Battery type
- LiFePO₄ (Lithium Iron Phosphate)
- Nominal energy
- 23.5 kWh
- Rated voltage
- 51.2 V
- Operation voltage range
- 44.8 – 57.6 V
- Maximum continuous current charging / unloading
- 200 A
- Peak current (15 s)
- 300 A
- Maximum load / discharge power
- 10.000 W (15 s)
- Depth download (DOD)
- ≥ 95%
- Scalabilitate
- Up to 15 units in parallel 354 kWh
- Comunicare / monitorizare
- RS485 / CAN (optional Wi-Fi / Bluetooth for monitoring)
- Estimated life cycles
- ≥ 6000 cycles (according to manufacturer)
- Charging temperature
- 0 … +55 °C
- Discharge temperature
- –20 … +55 °C
- Carcase protection grade
- IP21
- Installation
- Floor-mount (on the floor)
- Net weight
- ≈ 226 kg
- Dimensions (L × l × Q)
- 718 × 380 × 990 mm
- Guarantee
- 10 years (according to manufacturer)
