Three-phase hybrid inverter Deye SUN-20K-SG01HP3-EU-AM2 · 20 kW
4 photosRated power20 kW
ConnectionThree-phase
TypeHybrid
Description
Inverter Deye, model SUN-20K-SG01HP3-EU-AM2. Nominal power 20 kW. Hybrid, three-phase.
Trackers MPPT: 2 Independent. Battery voltage: Range HV - as specified (ex: 200 - 700 V DC). Maximum efficiency: up to ~ 97.5 - 98% (depending on conditions).
The battery and auxiliary equipment shall be selected separately according to the voltages, protocols and conditions in the model documentation. The reserve function may require additional equipment.
See below the technical data and documents available for size, protection, mounting and operating conditions. The approximate values and the source variants are kept explicitly; the commercial conditions are confirmed in the quotation.
Technical specifications
Identification
- Manufacturer
- Deye
- Model / reference
- SUN-20K-SG01HP3-EU-AM2
- Nominal filtering power
- 20 kW Power AC; not photovoltaic field power or extended configuration.
Technical specifications
- Model
- Deye SUN-20K-SG01HP3-EU-AM2
- Inverter type
- Three-phase hybrid (3 -phase), compatible batteries HV (high voltage)
- Nominal power AC
- 20 000 W (20 kW)
- Maximum apparent power (VA)
- 22 000 VA (overload permis)
- Nominal current per phase
- approx. 28.9 A / phase @ 400 V
- Frequency AC
- 50 / 60 Hz
- Power factor
- reglabil, ±1.0
- Allow unbalanced output on phases
- Yes - 100% load imbalance accepted
- Number MPPT
- 2 independent
- Maximum voltage DC PV
- 1000 V DC
- Interval MPPT / Start-up DC
- aprox. 180 – 850 V DC
- Maximum accepted power PV
- up to ~ 28 - 32 kW (depending on panels and lathes)
- Accepted battery voltage
- Range HV - as specified (ex: 200 - 700 V DC)
- Accessible Batteries Type
- Batteries HV (lithium, LiFePO, etc.)
- Maximum battery charge / discharge current
- approx. 50 A (depending on configuration)
- Operating modes
- On-grid, Off-grid, Hybrid, Back-up / EPS / UPS, AC-couple, Generator input
- Parallelization / System Extension
- Multi-unit parallel support, ideal for large systems
- Back-up / UPS
- Yes - automatic switching in case of network failure
- Maximum inverter efficiency
- to ~ 97.5 - 98% (depending on the conditions)
- Integrated protections
- Reverse polarity DC, protection AC / DC, SPD, overflow, short circuit, battery protection, insulation monitoring, anti-islanding, thermal protection
- Carcase protection class
- IP65 - suitable for indoor or outdoor mounting
- Operating temperature
- -30 ° C... +60 ° C (derating at extreme temperatures)
- Moisture allowed
- 0 - 100% (without condensation)
- Cooling
- Active ventilation (fan) / adaptive cooling
