Three-phase hybrid inverter Growatt SPH 7000 TL 3 BH-UP · 7 kW
2 photosRated power7 kW
ConnectionThree-phase
TypeHybrid
Description
Inverter Growatt, SPH model 7000 TL 3 BH-UP. Nominal power 7 kW. Hybrid, three-phase.
The batteries for SPH 7000 TL 3 BH-UP are High Voltage, in field 100 - 550 V DC according to sheet Growatt; the generic reference to 48 V in the source table has been corrected.
The electrical data, operating conditions and documents available are given below. Additional batteries and equipment shall be selected separately according to model documentation.
Technical specifications
Identification
- Manufacturer
- Growatt
- Model / reference
- SPH 7000TL3 BH-UP
- Nominal filtering power
- 7 kW Power AC; not photovoltaic field power or extended configuration.
Technical specifications
- Model
- Growatt SPH 7000TL3-BH-UP
- Inverter type
- Three-phase hybrid (3 -phase), battery compatible, "battery-ready"
- Nominal power AC
- 7000 W (7000 VA)
- Nominal apparent power
- 7000 VA
- Nominal output current (per phase / total)
- ≈ 10.6 A
- Fazare
- Triphased (3 -∞), with an asymmetrical output permitted
- Frequency AC
- 50 / 60 Hz
- Number MPPT
- 2 Trackers MPPT Independent
- Maximum power PV accepted
- ≈ 10 500 W
- Maximum voltage DC (PV)
- up to 1000 V DC (depends on configuration)
- Interval tipic MPPT / DC
- ~ 120 – 1000 V DC
- Battery compatibility
- Compatible batteries (liion type, lead acid, etc.) - "Battery-ready"
- Accepted battery voltage
- 100–550 V DC Checked on the attached manufacturer's sheet.
- Special functions
- UPS / Backup, automatic switching, 100% asymmetrical three-phase output, export limitation, phase-to-phase management
- System scalability / expansion
- Extension support and battery systems + PV + network
- Maximum inverter efficiency
- up to 98.2% (depending on the conditions)
- & Safety Protections
- SPD Type II on AC & DC, short circuit protection, anti-islanding, battery protection, phase balancing, string monitoring
- Carcase protection class
- IP65 - possible interior or exterior mounting
- Dimensions (L × Q × A)
- ≈ 505 × 453 × 198 mm
- Weight
- ≈ 30 kg
- Communication / monitoring interfaces
- USB / RS485
