Three-phase hybrid inverter Deye SUN-15K-SG01HP3-EU-AM2 · 15 kW
4 photosRated power15 kW
ConnectionThree-phase
TypeHybrid
Description
Inverter Deye, model SUN-15K-SG01HP3-EU-AM2. Nominal power 15 kW. Hybrid, three-phase.
Trackers MPPT: 2 independent trackers MPPT. Battery voltage: 160 - 700 V DC. Maximum efficiency: at 97.6%. Protection: IP65 - outer / interior housing.
The battery and auxiliary equipment shall be selected separately according to the voltages, protocols and conditions in the model documentation. The reserve function may require additional equipment.
See below the technical data and documents available for size, protection, mounting and operating conditions. The approximate values and the source variants are kept explicitly; the commercial conditions are confirmed in the quotation.
Technical specifications
Identification
- Manufacturer
- Deye
- Model / reference
- SUN-15K-SG01HP3-EU-AM2
- Nominal filtering power
- 15 kW Power AC; not photovoltaic field power or extended configuration.
Technical specifications
- Model
- Deye SUN-15K-SG01HP3-EU-AM2
- Inverter type
- Three-phase hybrid (3 -phase), compatible batteries HV (high voltage) 160 - 700 V DC
- Accepted battery voltage
- 160 – 700 V DC
- Accessible Batteries Type
- Lithium-ion / LiFePO
- Maximum charging / unloading current
- 50 A
- Number MPPT
- 2 trackers MPPT independente
- Voltage MPPT / DC input range
- 150 – 850 V DC
- Maximum voltage DC PV
- 1000 V DC
- Maximum power PV recommended
- up to ~ 30 000 W (depends on strings and panels)
- Nominal power AC
- 15 000 W (15 kW)
- Maximum apparent power (VA)
- 16 500 VA (overload)
- Nominal current AC (3 -phase)
- (see Annex 3, Figure 2)
- Maximum current AC (overload)
- (see Annex 3, Figure 2)
- Foncitation with unbalanced phases
- 100% unbalanced output allowed (each independent phase)
- Power factor
- Reglabil (PF 0.8 lag … 0.8 lead)
- THDi
- < 3 %
- Operating modes
- On-grid, off-grid, hybrid, back-up / UPS, AC-couple, generator input
- Parallelization / System Extension
- Up to 10 units in parallel (on-grid + off-grid)
- Output 100% unbalanced by phases
- Yes (each independent phase)
- External generator support
- Yes - generator module & battery charging management
- Maximum inverter efficiency
- ≈ 97.6 %
- Efficiency MPPT / conversion PV - AC
- > 99 % MPPT ; global ridicat
- Carcase protection grade
- IP65 - outer / interior housing
- Temperature range operation
- -40 °C … +60 °C
- Moisture allowed
- 0 - 100% (without condensation)
